GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 7-5 - Common Diagnostics 7-19
7-5-4-3 P3RLY/P2RLY
These programs are provided for testing the P3RLY/P2RLY board.
NOTE: A Convex Probe is needed for RLY Channel Test.
7-5-4-4 ACWD
These programs are provided for testing the ACWD board.
Table 7-4 FRU Test, P3RLY Diagnostics Menu
Menu
Descriptions
User
Level Tools
Full Test
Performs all of the P3RLY/P2RLY board tests listed below
GE FE
Only
None
Assy Revision
Test
Test EEPROM.
Send test pattern to write to EEPROM and readDisplays the board revision of the
P3RLY/P2RLY board
All None
FEBUS Test
Checks if the DSP in SYSCONPM/SYSCONCM can access the P3RLY/P2RLY board
via FE bus.
GE FE
Only
None
SHV Test
Send the command to SHV resister in P3RLY/P2RLY board to read SHV status.
GE FE
Only
None
OPEN Test
Checks whether probe connected or not on P3RLY/P2RLY.
GE FE
Only
Probe
PROBE CODE
Checks if the 8 bits of the Probe Code in the probe connector is properly connected.
If connected probe is available, display code and Probe name.
Table 7-5 FRU Test, ACWD Diagnostics Menu
Menu
Descriptions
User
Level Tools
Full Test
Performs all of the ACWD board test listed below All None
Assy Revision
TEst
Test EEPROM.Send test pattern to write to EEPROM and readDisplays the board
revision of the ACWD board
All None
USC Interface
Test
Checks if the DSP in SYSCONPM/SYSCNCM can access the ACWD boards via USB
bus.
All None
FEBUS Test
Allows SYSCONPM/SYSCNCM to access FE bus interface in the ACWD in order to
check if FE bus line is normal.
IQ Data Read
Send the command to perform CW scanning, read IQ data from assigned memory,
analyze the data with FFT algorithm.
Probe
Connection
Checks whether ACWD probe connected or not.
Channel Test
Generate test pattern, perform 32 channel scanning in ACWD, read the data and
analyze it.
