GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 7-7 - Trouble Shooting Tree 7-31
7-7-6 Monitor Troubleshooting (cont’d)
• Monitor does not work
- Check AC circuit breaker
- Verify power is present at monitor outlet
- Check if video is present at backplane
• Prints do not match monitor
- Verify factory default settings. Chapter 18 in the User Manual calls out suggested settings for
various exam and lighting conditions.
• Video test patterns are not clear, bright, parallel or square
- Replace the monitor
Figure 7-17 Monitor Troubleshooting
Yes
Is the shutdown dialog
box displayed?
Did the scanner
Shut off?
Yes
Depress and hold the ON/OFF switch on
the scanner for approximately 5
seconds.
If the scanner fails to Shut Off, follow the
step below.
Check cable connection refer 7-10-5
If the scanner still does not Shut off,
Switch the circuit breaker to the OFF
position.
NO
NO
Press once the on/off switch.
Shutdown the scanner from a software
screen or depress the ON/OFF switch
Switch the breaker to the
OFF position.to
completely Power Down
the scanner.
Press and hold on/off switch until
system shut down.
To Next Page
