GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
1-6 Section 1-2 - Important Conventions
"OFF/Standby" Indicates the power off/
standby position of the power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Adjacent to On-Off/Standby Switch
"Mains ON" Indicates the power on position of
the mains power switch.
"ON" Indicates the power on position of the
power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Front Panel Switch
"Protective Earth" Indicates the protective
earth (grounding) terminal.
Internal
Indicates an earth GROUND potential
Product schematics
Peripherals
Table 1-5 Product Icons
LABEL/SYMBOL PURPOSE/MEANING LOCATION
To Next Page
