GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 8-7 - Mechanical Option Installation instruction 8-181
8-7-3 BT11 BW Printer Option Installation
1.) This section describes the installation procedure of the BW Printer option.
2.) Assemble the BW PRINTER to BW PRINTER FIX BRKT with screwing 4 screws (2306562, FH
M3X6).
3.) Assemble the BT11 BW PRINTER ASSY to SYSTEM using 2 SCREWS (5176744, BH M4X20).
Figure 8-250 BT11 BW PRINTER Option Installation
Figure 8-251 BT11 BW PRINTER Option Installation
To Next Page
