GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
3 - 68 Section 3-11 - Connectivity Setup
3-11-3 Stand-alone LOGIQ S8
If digital images or 3D/4D data sets (if available) are stored, they should be saved in the Archive (Image
Management System software).
For Image Management functionality refer to the Basic User Manual supplied with the LOGIQ S8.
Physical Connection:
No network connection needed.
3-11-4 LOGIQ S8 + PC within a “Sneaker Net”
A PC is used for review and work on studies acquired on one or more LOGIQ S8 scanners without being
connected in a network.
The images are first stored on the LOGIQ S8 scanner’s hard drive (Archive) and then exported from the
scanner’s hard drive to a sneaker device (e.g., DVD/CD), and finally imported from the sneaker device
to the PC’s internal hard drive.
For Image Management functionality refer to the Basic User Manual supplied with the LOGIQ S8.
Physical Connection:
No network connection needed.
3-11-5 Connection between LOGIQ S8 and DICOM Server
In this configuration, the LOGIQ S8 is configured to work with a DICOM server in a network
environment. Usually, this will be the hospital network. Images are first saved on the local image buffer
on the scanner. At the end of the examination, the images are sent to the DICOM server via a DICOM
spooler. This scenario requires that the scanner is configured to be connected to the DICOM server.
Physical Connection:
You will need one network cable.
1.) Connect one end of the cable to the Ethernet connector on the LOGIQ S8.
2.) Connect the other end of the cable to the wall outlet.
NOTE: If a Peer-to-Peer Network is connected to the hospital’s network, you may connect the LOGIQ S8 to
the Peer-to-Peer Network.
For more details refer to Section 3-12 "Configuring Connectivity" on page 3-72.
NOTICE
!! NOTICE:
To avoid loss of essential data, it is highly recommended to export/backup patient data as well as
measurements at least once a month.
NOTICE
!! NOTICE:
To avoid loss of essential data, it is highly recommended to export/backup patient data as well as
measurements at least once a month.
