GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
3 - 12 Section 3-6 - Completing the Set Up
Section 3-6
Completing the Set Up
3-6-1 System Specifications
3-6-1-1 System requirements verification
• Verify that the site meets the requirements listed in (see: Section 2-3 "Facility needs" on page 2-7).
• Verify that the specifications below don’t conflict with any on-site conditions.
3-6-1-2 Physical Dimensions
* with low cabinet option.
3-6-1-3 Acoustic Noise Output
max. 50 dB(A)
Table 3-6 LOGIQ S8 R1 to R3 (without Peripherals)
Height Width Depth Weight
1720 mm, 67.7 in (max)
1150 mm, 45.3 in (min) *
500 mm, 19.7 in (Keyboard)
620 mm, 24.4 in (Caster)
865 mm, 34.1 in (max)
795 mm, 31.3 in (Caster)
85 kg
(187.4 lbs.)
Table 3-7 LOGIQ S8 R4 and later (without Peripherals)
Height Width Depth Weight
1760 mm, 69.3 in (max)
1150 mm, 45.3in (min, 23” LCD)
1100 mm, 43.3in (min, 22” OLED)
520 mm, 20.5 in (Keyboard)
530 mm, 20.9 in (Caster)
561 mm, 22.1 in (23” LCD Monitor)
527mm, 20.7in (22” OLED Monitor)
865 mm, 34.1 in (max)
795 mm, 31.3 in (Caster) 85 kg
(187.4 lbs.)
Table 3-8 LOGIQ E8 R2 and R3 (without Peripherals)
Height Width Depth Weight
1750 mm (max)
1250 mm (min)
500 mm (Keyboard)
620 mm (Caster)
865 mm (max)
795 mm (Caster)
97 kg
Table 3-9 LOGIQ E8 R4 and later (without Peripherals)
Height Width Depth Weight
1760 mm (max)
1240 mm (min)
520 mm (Keyboard)
530 mm (Caster)
527mm (22” OLED Monitor)
865 mm (max)
795 mm (Caster)
97 kg
