DIRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
5 - 26 Section 5-9 - Air Flow Distribution
Section 5-9
Air Flow Distribution
5-9-1 Air Flow Distribution
Through the filter grid on the front of the system, air flow into the LOGIQ S8.
By means of the 1 FAN, air is blown through the nest-box, and the warm air exits the system through
holes in the left side panel and rear of the system.
Figure 5-17 Air Inlet/Outlet
Main Air
inlet
(Filter grid)
Main Air
Outlet
(Rear)
(Side)
