GE MAC 1600

ElectromagneticCompatibility
ImmunityTest
ComplianceTest
Level
ComplianceLevel
Electromagnetic
Environment-
Guidance
Electrostatic
discharge(ESD)
•IEC
60601-1-2:2007
•IEC61000-4-2::
2001
±2/4/6kVindirect
±2/4/6kVdirect
±2/4/8kVair
±2/4/6kVindirect
±2/4/6kVdirect
±2/4/8kVair
Exception:
±2/4kVairforPaper
Queuesensors
Floorsshouldbe
wood,concreteor
ceramictile.Ifoors
arecoveredwith
syntheticmaterial,
therelativehumidity
shouldbeatleast
30%.
Electricalfast
transient/burst(EFT)
•IEC
60601-1-2:2007
•IEC61000-4-4:
2004
±2kVforpower
supplylines
±1kVfor
input/outputlines
±2kVforpower
supplylines
±1kVfor
input/outputlines
Mainspower
shouldbethatof
atypicalcommercial
orhospital
environment.
FastTransientSurge
(FTS)
•IEC
60601-1-2:2007
•IEC61000-4-5:
2005
±1kVdifferential
mode
±2kVcommonmode
±1kVdifferential
mode
±2kVcommonmode
Mainspower
shouldbethatof
atypicalcommercial
orhospital
environment.
Voltagedips,short
interruptionsand
voltagevariationson
powersupplyinput
lines
•IEC
60601-1-2:2007
•IEC
61000-4-11:
2004
<5%Ut(>95%dipin
Ut)for0.5cycles
<40%Ut(>60%dipin
Ut)for5cycles
<70%Ut(>30%dipin
Ut)for25cycles
<5%Ut(>95%dipin
Ut)for5s
<5%Ut(>95%dipin
Ut)for0.5cycles
<40%Ut(>60%dipin
Ut)for5cycles
<70%Ut(>30%dipin
Ut)for25cycles
<5%Ut(>95%dipin
Ut)for5s
Mainspower
shouldbethatof
atypicalcommercial
orhospital
environment.If
theuserrequires
continuedoperation
duringpowermains
interruptions,itis
recommendedthat
powerbesupplied
fromanapplicably
rateduninterruptible
powersupplyora
battery.
Powerfrequency
(50/60Hz)magnetic
eld
•IEC
60601-1-2:2007
•IEC61000-4-8:
2001
3A/m3A/m
Powerfrequency
magneticelds
shouldbeatlevels
characteristicsofa
typicallocationina
typicalcommercial
orhospital
environment.
NOTEU
t
istheACmainsvoltagepriortoapplicationofthetestlevel.
