moisture.IQ User’s Manual 61
Chapter 5. Using the Configuration Menu
5.1.1 The Probe Configuration Screen (cont.)
Table 8: Available Measurement Modes and Units
Selected
Measurement
Mode
Unit Description
Displayed
Measurement Mode
Displayed
Units
Oxygen % = Percent Oxygen (default) Oxygen %
PPM = Parts Per Million Oxygen PPM
PPB = Parts Per Billion Oxygen PPB
μ = Microamps (Diagnostic Mode) Oxygen μ
Hygrometry DP °C = Dew/Frost Point Degrees Celsius (default) Dew Point °C
DP °F = Dew/Frost Point Temperature Fahrenheit Dew Point °F
PPMv = Parts per Million of Water by Volume H
2
O PPMv
PPBv = Parts per Billion of Water by Volume H
2
O PPBv
PPMw = Parts per Million of Water by Weight H
2
O PPMw
RH % = Relative Humidity Rel. Humidity %
MMSCFig = Pounds of Water per Million Std. Cubic Feet in Ideal
Gas
H
2
O/MMSCFig Lbs
MMSCFng = Pounds of Water per Million Std. Cubic Feet in
Natural Gas
H
2
O/MMSCFng Lbs
Equiv DP°C NG = Equivalent Dew/Frost Point Degrees Celsius in
Natural Gas
Equiv DP °C
Equiv DP°F NG = Equivalent Dew/Frost Point Degrees
Fahrenheit in Natural Gas
Equiv DP °F
PPMv/ng = Parts Per Million by Volume in Natural Gas H
2
O/Natural Gas PPMv
g/m
3
= grams per meter cubed
Hygro
g/m
3
mg/m
3
= milligrams per meter cubed
Hygro
mg/m
3
Pw/kPa = Vapor Pressure in KiloPascals Vapor Pressure kPa
Pw/mmHg = Vapor Pressure in Mercury Vapor Pressure mmHg
MH = MH* (Diagnostic Mode) H
2
OMH
FH = FH* (Diagnostic Mode) H
2
OFH
Temperature °C = Degrees Celsius (default) Temperature °C
°F = Degrees Fahrenheit Temperature °F
Kelvin = Kelvin Temperature K
°R = Degrees Rankine Temperature °R
