GE Multilin G60 Generator Protection System 5-23
5 SETTINGS 5.2 PRODUCT SETUP
5
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
 TRANSMISSION
The general transmission settings are shown below:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
 TRANSMISSION  GENERAL
The DEFAULT GSSE/GOOSE UPDATE TIME sets the time between GSSE or GOOSE messages when there are no remote out-
put state changes to be sent. When remote output data changes, GSSE or GOOSE messages are sent immediately. This
setting controls the steady-state heartbeat time interval.
The
DEFAULT GSSE/GOOSE UPDATE TIME setting is applicable to GSSE, fixed G60 GOOSE, and configurable GOOSE.
The GSSE settings are shown below:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
 TRANSMISSION  GSEE
These settings are applicable to GSSE only. If the fixed GOOSE function is enabled, GSSE messages are not transmitted.
The GSSE ID setting represents the IEC 61850 GSSE application ID name string sent as part of each GSSE message. This
string identifies the GSSE message to the receiving device. In G60 releases previous to 5.0x, this name string was repre-
sented by the
RELAY NAME setting.
 TRANSMISSION

 GENERAL

MESSAGE
 GSSE

MESSAGE
 FIXED GOOSE

MESSAGE
 CONFIGURABLE
 GOOSE
 GENERAL

DEFAULT GSSE/GOOSE
UPDATE TIME: 60 s
Range: 1 to 60 s in steps of 1
 GSSE

GSSE FUNCTION:
Enabled
Range: Enabled, Disabled
MESSAGE
GSSE ID:
GSSEOut
Range: 65-character ASCII string
MESSAGE
DESTINATION MAC:
000000000000
Range: standard MAC address
