5.7.12 MONITORING ELEMENTS
a) MAIN MENU
PATH: SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS
b) VT FUSE FAILURE
PATH: SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS  VT FUSE FAILURE 1(4)
Every signal source includes a fuse failure scheme.
The VT fuse failure detector can be used to raise an alarm and/or block elements that may operate incorrectly for a full or
partial loss of AC potential caused by one or more blown fuses. Some elements that might be blocked (via the BLOCK input)
are distance, voltage restrained overcurrent, and directional current.
There are two classes of fuse failure that may occur:
• Class A: loss of one or two phases.
• Class B: loss of all three phases.
Different means of detection are required for each class. An indication of class A failures is a significant level of negative-
sequence voltage, whereas an indication of class B failures is when positive sequence current is present and there is an
insignificant amount of positive sequence voltage. These noted indications of fuse failure could also be present when faults
are present on the system, so a means of detecting faults and inhibiting fuse failure declarations during these events is pro-
vided. Once the fuse failure condition is declared, it will be sealed-in until the cause that generated it disappears.
An additional condition is introduced to inhibit a fuse failure declaration when the monitored circuit is de-energized; positive-
sequence voltage and current are both below threshold levels.
The function setting enables and disables the fuse failure feature for each source.
 MONITORING
 ELEMENTS
 VT FUSE FAILURE 1

See page 5–243.
MESSAGE
 VT FUSE FAILURE 2

See page 5–243.
MESSAGE
 VT FUSE FAILURE 3

See page 5–243.
MESSAGE
 VT FUSE FAILURE 4

See page 5–243.
MESSAGE
 THERMAL OVERLOAD
 PROTECTION
See page 5–245.
 VT FUSE FAILURE 1

VT FUSE FAILURE 1
FUNCTION: Disabled
Range: Disabled, Enabled
MESSAGE
 NEUTRAL WIRE OPEN 1
 DETECTION: Disabled
Range: Disabled, Enabled
MESSAGE
 NEUTRAL WIRE OPEN 1
 3 HARM PKP: 0.100
0.000 to 3.000 pu in steps of 0.001
