6-14 G60 Generator Protection System GE Multilin
6.3 METERING 6 ACTUAL VALUES
6
6.3.2 STATOR DIFFERENTIAL
PATH: ACTUAL VALUES  METERING  STATOR DIFFERENTIAL  STATOR DIFFERENTIAL
The phasors of differential and restraint currents are displayed in primary amperes.
6.3.3 SOURCES
a) MAIN MENU
PATH: ACTUAL VALUES  METERING  SOURCE SRC1
This menu displays the metered values available for each source.
Metered values presented for each source depend on the phase and auxiliary VTs and phase and ground CTs assignments
for this particular source. For example, if no phase VT is assigned to this source, then any voltage, energy, and power val-
ues will be unavailable.
 STATOR
 DIFFERENTIAL
STATOR DIFF OPERATE
Iad: 0.00 A
MESSAGE
STATOR DIFF RESTRAIN
Iar: 0.00 A
MESSAGE
STATOR DIFF OPERATE
Ibd: 0.00 A
MESSAGE
STATOR DIFF RESTRAIN
Iar: 0.00 A
MESSAGE
STATOR DIFF OPERATE
Icd: 0.00 A
MESSAGE
STATOR DIFF RESTRAIN
Icr: 0.00 A
 SOURCE SRC 1

 PHASE CURRENT
 SRC 1
See page 6–15.
MESSAGE
 GROUND CURRENT
 SRC 1
See page 6–15.
MESSAGE
 PHASE VOLTAGE
 SRC 1
See page 6–16.
MESSAGE
 AUXILIARY VOLTAGE
 SRC 1
See page 6–16.
MESSAGE
 POWER
 SRC 1
See page 6–17.
MESSAGE
 ENERGY
 SRC 1
See page 6–18.
MESSAGE
 FREQUENCY
 SRC 1
See page 6–18.
MESSAGE
 CURRENT HARMONICS
 SRC 1
See page 6–18.
MESSAGE
 VOLTAGE HARMONICS
 SRC 1
See page 6–19.
