6.3 METERING 6 ACTUAL VALUES
6
d) PHASE VOLTAGE METERING
PATH: ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE VOLTAGE
The metered phase voltage values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
e) AUXILIARY VOLTAGE METERING
PATH: ACTUAL VALUES  METERING  SOURCE SRC 1  AUXILIARY VOLTAGE
The metered auxiliary voltage values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see
SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
 PHASE VOLTAGE
 SRC 1
SRC 1 RMS Vag:
0.00 V
MESSAGE
SRC 1 RMS Vbg:
0.00 V
MESSAGE
SRC 1 RMS Vcg:
0.00 V
MESSAGE
SRC 1 PHASOR Vag:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vbg:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vcg:
0.000 V 0.0°
MESSAGE
SRC 1 RMS Vab:
0.00 V
MESSAGE
SRC 1 RMS Vbc:
0.00 V
MESSAGE
SRC 1 RMS Vca:
0.00 V
MESSAGE
SRC 1 PHASOR Vab:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vbc:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vca:
0.000 V 0.0°
MESSAGE
SRC 1 ZERO SEQ V0:
0.000 V 0.0°
MESSAGE
SRC 1 POS SEQ V1:
0.000 V 0.0°
MESSAGE
SRC 1 NEG SEQ V2:
0.000 V 0.0°
 AUXILIARY VOLTAGE
 SRC 1
SRC 1 RMS Vx:
0.00 V
MESSAGE
SRC 1 PHASOR Vx:
0.000 V 0.0°
