5-34 G60 Generator Protection System GE Multilin
5.2 PRODUCT SETUP 5 SETTINGS
5
The breaker configuration settings are shown below. Changes to these values will not take effect until the UR is restarted:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  XCBR CONFIGURATION
The CLEAR XCBR1 OpCnt setting represents the breaker operating counter. As breakers operate by opening and closing, the
XCBR operating counter status attribute (OpCnt) increments with every operation. Frequent breaker operation may result
in very large OpCnt values over time. This setting allows the OpCnt to be reset to “0” for XCBR1.
 XCBR
 CONFIGURATION
XCBR1 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
MESSAGE
XCBR2 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
MESSAGE
XCBR3 ST.LOC OPERAND
Off
Range: FlexLogic™ operand

MESSAGE
XCBR6 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
MESSAGE
CLEAR XCBR1 OpCnt:
No
Range: No, Yes
MESSAGE
CLEAR XCBR2 OpCnt:
No
Range: No, Yes
MESSAGE
CLEAR XCBR3 OpCnt:
No
Range: No, Yes

MESSAGE
CLEAR XCBR6 OpCnt:
No
Range: No, Yes
