B-24 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
4D60 ...Repeated for User-Definable Display 12
4D80 ...Repeated for User-Definable Display 13
4DA0 ...Repeated for User-Definable Display 14
4DC0 ...Repeated for User-Definable Display 15
4DE0 ...Repeated for User-Definable Display 16
User Programmable Pushbuttons (Read/Write Setting) (12 modules)
4E00 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F109 2 (Disabled)
4E01 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
4E0B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
4E15 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
4E1F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
4E20 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
4E21 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
4E22 User Programmable Pushbutton 1 LED Operand 0 to 65535 --- 1 F300 0
4E23 User Programmable Pushbutton 1 Autoreset Delay 0 to 600 s 0.05 F001 0
4E24 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
4E25 User Programmable Pushbutton 1 Local Lock 0 to 65535 --- 1 F300 0
4E26 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
4E27 User Programmable Pushbutton 1 Remote Lock 0 to 65535 --- 1 F300 0
4E28 User Programmable Pushbutton 1 Reset 0 to 65535 --- 1 F300 0
4E29 User Programmable Pushbutton 1 Set 0 to 65535 --- 1 F300 0
4E2A ...Repeated for User Programmable Pushbutton 2
4E54 ...Repeated for User Programmable Pushbutton 3
4E7E ...Repeated for User Programmable Pushbutton 4
4EA8 ...Repeated for User Programmable Pushbutton 5
4ED2 ...Repeated for User Programmable Pushbutton 6
4EFC ...Repeated for User Programmable Pushbutton 7
4F26 ...Repeated for User Programmable Pushbutton 8
4F50 ...Repeated for User Programmable Pushbutton 9
4F7A ...Repeated for User Programmable Pushbutton 10
4FA4 ...Repeated for User Programmable Pushbutton 11
4FCE ...Repeated for User Programmable Pushbutton 12
Flexlogic (Read/Write Setting)
5000 FlexLogic™ Entry (512 items) 0 to 65535 --- 1 F300 16384
RTD Inputs (Read/Write Setting) (48 modules)
5400 RTD Input 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5401 RTD Input 1 ID --- --- --- F205 “RTD Ip 1“
5407 RTD Input 1 Type 0 to 3 --- 1 F174 0 (100 ohm Platinum)
5407 RTD Input 1 Application 0 to 5 --- 1 F550 0 (None)
5407 RTD Input 1 Alarm Temperature 1 to 249 °C 1 F001 130
5407 RTD Input 1 Alarm Pickup Delay 0 to 600 s 0.01 F001 0
540B RTD Input 1 Trip Temperature 1 to 249 °C 1 F001 130
540C RTD Input 1 Trip Pickup Delay 0 to 600 s 0.01 F001 0
540D RTD Input 1 Trip Reset Delay 0 to 600 s 0.01 F001 0
540E RTD Input 1 Trip Voting 0 to 48 --- 1 F551 0
540F RTD Input 1 Open 0 to 2 --- 1 F552 0 (None)
5410 RTD Input 1 Block 0 to 65535 --- 1 F300 0
5411 RTD Input 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5412 RTD Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5413 ...Repeated for RTD Input 2
5426 ...Repeated for RTD Input 3
5439 ...Repeated for RTD Input 4
544C ...Repeated for RTD Input 5
545F ...Repeated for RTD Input 6
Table B–9: MODBUS MEMORY MAP (Sheet 17 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
To Next Page
