B-52 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
B501 IEC 61850 GGIO1 Indication operands (128 items) --- --- 1 F300 0
IEC 61850 Configurable GOOSE Transmission (Read/Write Setting) (8 modules)
B5A0 IEC 61850 Configurable GOOSE Function 0 to 1 --- 1 F102 0 (None)
B5A1 IEC 61850 Configurable GOOSE ID --- --- --- F209 “GOOSEOut_x_”
B5C2 Configurable GOOSE Destination MAC Address --- --- --- F072 0
B5C5 IEC 61850 Configurable GOOSE VLAN Transmit Priority 0 to 7 --- 1 F001 4
B5C6 IEC 61850 Configurable GOOSE VLAN ID 0 to 4095 --- 1 F001 0
B5C7 IEC 61850 Configurable GOOSE ETYPE APPID 0 to 16383 --- 1 F001 0
B5C8 IEC 61850 Configurable GOOSE ConfRev 1 to 4294967295 --- 1 F003 1
B5CA IEC 61850 Configurable GOOSE Retransmission Curve 0 to 3 --- 1 F611 3 (Relaxed)
B5CB Configurable GOOSE dataset items for transmission
(64 items)
0 to 542 --- 1 F616 0 (None)
B60B ...Repeated for Module 2
B676 ...Repeated for Module 3
B6E1 ...Repeated for Module 4
B74C ...Repeated for Module 5
B7B7 ...Repeated for Module 6
B822 ...Repeated for Module 7
B88D ...Repeated for Module 8
IEC 61850 Configurable GOOSE Reception (Read/Write Setting) (8 modules)
B900 Configurable GOOSE dataset items for reception
(32 items)
0 to 32 --- 1 F233 0 (None)
B940 ...Repeated for Module 2
B980 ...Repeated for Module 3
B9C0 ...Repeated for Module 4
BA00 ...Repeated for Module 5
BA40 ...Repeated for Module 6
BA80 ...Repeated for Module 7
BAC0 ...Repeated for Module 8
Contact Inputs (Read/Write Setting) (96 modules)
BB00 Contact Input 1 Name --- --- --- F205 “Cont Ip 1“
BB06 Contact Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
BB07 Contact Input 1 Debounce Time 0 to 16 ms 0.5 F001 20
BB08 ...Repeated for Contact Input 2
BB10 ...Repeated for Contact Input 3
BB18 ...Repeated for Contact Input 4
BB20 ...Repeated for Contact Input 5
BB28 ...Repeated for Contact Input 6
BB30 ...Repeated for Contact Input 7
BB38 ...Repeated for Contact Input 8
BB40 ...Repeated for Contact Input 9
BB48 ...Repeated for Contact Input 10
BB50 ...Repeated for Contact Input 11
BB58 ...Repeated for Contact Input 12
BB60 ...Repeated for Contact Input 13
BB68 ...Repeated for Contact Input 14
BB70 ...Repeated for Contact Input 15
BB78 ...Repeated for Contact Input 16
BB80 ...Repeated for Contact Input 17
BB88 ...Repeated for Contact Input 18
BB90 ...Repeated for Contact Input 19
BB98 ...Repeated for Contact Input 20
BBA0 ...Repeated for Contact Input 21
BBA8 ...Repeated for Contact Input 22
BBB0 ...Repeated for Contact Input 23
Table B–9: MODBUS MEMORY MAP (Sheet 45 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
