B.4 MEMORY MAPPING APPENDIX B
B
BD68 ...Repeated for Contact Input 78
BD70 ...Repeated for Contact Input 79
BD78 ...Repeated for Contact Input 80
BD80 ...Repeated for Contact Input 81
BD88 ...Repeated for Contact Input 82
BD90 ...Repeated for Contact Input 83
BD98 ...Repeated for Contact Input 84
BDA0 ...Repeated for Contact Input 85
BDA8 ...Repeated for Contact Input 86
BDB0 ...Repeated for Contact Input 87
BDB8 ...Repeated for Contact Input 88
BDC0 ...Repeated for Contact Input 89
BDC8 ...Repeated for Contact Input 90
BDD0 ...Repeated for Contact Input 91
BDD8 ...Repeated for Contact Input 92
BDE0 ...Repeated for Contact Input 93
BDE8 ...Repeated for Contact Input 94
BDF0 ...Repeated for Contact Input 95
BDF8 ...Repeated for Contact Input 96
Contact Input Thresholds (Read/Write Setting)
BE00 Contact Input n Threshold, n = 1 to 24 (24 items) 0 to 3 --- 1 F128 1 (33 Vdc)
Virtual Inputs (Read/Write Setting) (64 modules)
BE30 Virtual Input 1 Function 0 to 1 --- 1 F102 0 (Disabled)
BE31 Virtual Input 1 Name --- --- --- F205 “Virt Ip 1“
BE37 Virtual Input 1 Programmed Type 0 to 1 --- 1 F127 0 (Latched)
BE38 Virtual Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
BE39 Reserved (3 items) --- --- --- F001 0
BE3C ...Repeated for Virtual Input 2
BE48 ...Repeated for Virtual Input 3
BE54 ...Repeated for Virtual Input 4
BE60 ...Repeated for Virtual Input 5
BE6C ...Repeated for Virtual Input 6
BE78 ...Repeated for Virtual Input 7
BE84 ...Repeated for Virtual Input 8
BE90 ...Repeated for Virtual Input 9
BE9C ...Repeated for Virtual Input 10
BEA8 ...Repeated for Virtual Input 11
BEB4 ...Repeated for Virtual Input 12
BEC0 ...Repeated for Virtual Input 13
BECC ...Repeated for Virtual Input 14
BED8 ...Repeated for Virtual Input 15
BEE4 ...Repeated for Virtual Input 16
BEF0 ...Repeated for Virtual Input 17
BEFC ...Repeated for Virtual Input 18
BF08 ...Repeated for Virtual Input 19
BF14 ...Repeated for Virtual Input 20
BF20 ...Repeated for Virtual Input 21
BF2C ...Repeated for Virtual Input 22
BF38 ...Repeated for Virtual Input 23
BF44 ...Repeated for Virtual Input 24
BF50 ...Repeated for Virtual Input 25
BF5C ...Repeated for Virtual Input 26
BF68 ...Repeated for Virtual Input 27
BF74 ...Repeated for Virtual Input 28
Table B–9: MODBUS MEMORY MAP (Sheet 47 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
