GE Multilin G60 Generator Protection System B-57
APPENDIX B B.4 MEMORY MAPPING
B
C358 ...Repeated for Virtual Output 70
C360 ...Repeated for Virtual Output 71
C368 ...Repeated for Virtual Output 72
C370 ...Repeated for Virtual Output 73
C378 ...Repeated for Virtual Output 74
C380 ...Repeated for Virtual Output 75
C388 ...Repeated for Virtual Output 76
C390 ...Repeated for Virtual Output 77
C398 ...Repeated for Virtual Output 78
C3A0 ...Repeated for Virtual Output 79
C3A8 ...Repeated for Virtual Output 80
C3B0 ...Repeated for Virtual Output 81
C3B8 ...Repeated for Virtual Output 82
C3C0 ...Repeated for Virtual Output 83
C3C8 ...Repeated for Virtual Output 84
C3D0 ...Repeated for Virtual Output 85
C3D8 ...Repeated for Virtual Output 86
C3E0 ...Repeated for Virtual Output 87
C3E8 ...Repeated for Virtual Output 88
C3F0 ...Repeated for Virtual Output 89
C3F8 ...Repeated for Virtual Output 90
C400 ...Repeated for Virtual Output 91
C408 ...Repeated for Virtual Output 92
C410 ...Repeated for Virtual Output 93
C418 ...Repeated for Virtual Output 94
C420 ...Repeated for Virtual Output 95
C428 ...Repeated for Virtual Output 96
Mandatory (Read/Write Setting)
C430 Test Mode Function 0 to 1 --- 1 F245 0 (Disabled)
C431 Force VFD and LED 0 to 1 --- 1 F126 0 (No)
C432 Test Mode Forcing 0 to 65535 --- 1 F300 1
C436 Relay Reboot Command 0 to 1 --- 1 F126 0 (No)
Clear commands (read/write)
C433 Clear All Relay Records Command 0 to 1 --- 1 F126 0 (No)
Contact Outputs (Read/Write Setting) (64 modules)
C440 Contact Output 1 Name --- --- --- F205 “Cont Op 1"
C446 Contact Output 1 Operation 0 to 65535 --- 1 F300 0
C447 Contact Output 1 Seal In 0 to 65535 --- 1 F300 0
C448 Latching Output 1 Reset 0 to 65535 --- 1 F300 0
C449 Contact Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
C44A Latching Output 1 Type 0 to 1 --- 1 F090 0 (Operate-dominant)
C44B Reserved --- --- --- F001 0
C44C ...Repeated for Contact Output 2
C458 ...Repeated for Contact Output 3
C464 ...Repeated for Contact Output 4
C470 ...Repeated for Contact Output 5
C47C ...Repeated for Contact Output 6
C488 ...Repeated for Contact Output 7
C494 ...Repeated for Contact Output 8
C4A0 ...Repeated for Contact Output 9
C4AC ...Repeated for Contact Output 10
C4B8 ...Repeated for Contact Output 11
C4C4 ...Repeated for Contact Output 12
C4D0 ...Repeated for Contact Output 13
Table B–9: MODBUS MEMORY MAP (Sheet 50 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
