GE Multilin G60 Generator Protection System B-59
APPENDIX B B.4 MEMORY MAPPING
B
Control Pushbuttons (Read/Write Setting) (7 modules)
C760 Control Pushbutton 1 Function 0 to 1 --- 1 F102 0 (Disabled)
C761 Control Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
C762 ...Repeated for Control Pushbutton 2
C764 ...Repeated for Control Pushbutton 3
C766 ...Repeated for Control Pushbutton 4
C768 ...Repeated for Control Pushbutton 5
C76A ...Repeated for Control Pushbutton 6
C76C ...Repeated for Control Pushbutton 7
Clear Records (Read/Write Setting)
C771 Clear User Fault Reports operand 0 to 65535 --- 1 F300 0
C772 Clear Event Records operand 0 to 65535 --- 1 F300 0
C773 Clear Oscillography operand 0 to 65535 --- 1 F300 0
C774 Clear Data Logger operand 0 to 65535 --- 1 F300 0
C77D Clear Energy operand 0 to 65535 --- 1 F300 0
C77F Clear Unauthorized Access operand 0 to 65535 --- 1 F300 0
C781 Clear Platform Direct Input/Output Statistics operand 0 to 65535 --- 1 F300 0
C782 Reserved (13 items) --- --- --- F001 0
Force Contact Inputs/Outputs (Read/Write Settings)
C7A0 Force Contact Input x State (96 items) 0 to 2 --- 1 F144 0 (Disabled)
C800 Force Contact Output x State (64 items) 0 to 3 --- 1 F131 0 (Disabled)
Direct Inputs/Outputs (Read/Write Setting)
C880 Direct Device ID 1 to 16 --- 1 F001 1
C881 Direct I/O Channel 1 Ring Configuration Function 0 to 1 --- 1 F126 0 (No)
C882 Platform Direct I/O Data Rate 64 to 128 kbps 64 F001 64
C883 Direct I/O Channel 2 Ring Configuration Function 0 to 1 --- 1 F126 0 (No)
C884 Platform Direct I/O Crossover Function 0 to 1 --- 1 F102 0 (Disabled)
Direct input/output commands (Read/Write Command)
C888 Direct input/output clear counters command 0 to 1 --- 1 F126 0 (No)
Direct inputs (Read/Write Setting) (96 modules)
C890 Direct Input 1 Device Number 0 to 16 --- 1 F001 0
C891 Direct Input 1 Number 0 to 96 --- 1 F001 0
C892 Direct Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
C893 Direct Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
C894 ...Repeated for Direct Input 2
C898 ...Repeated for Direct Input 3
C89C ...Repeated for Direct Input 4
C8A0 ...Repeated for Direct Input 5
C8A4 ...Repeated for Direct Input 6
C8A8 ...Repeated for Direct Input 7
C8AC ...Repeated for Direct Input 8
C8B0 ...Repeated for Direct Input 9
C8B4 ...Repeated for Direct Input 10
C8B8 ...Repeated for Direct Input 11
C8BC ...Repeated for Direct Input 12
C8C0 ...Repeated for Direct Input 13
C8C4 ...Repeated for Direct Input 14
C8C8 ...Repeated for Direct Input 15
C8CC ...Repeated for Direct Input 16
C8D0 ...Repeated for Direct Input 17
C8D4 ...Repeated for Direct Input 18
C8D8 ...Repeated for Direct Input 19
C8DC ...Repeated for Direct Input 20
C8E0 ...Repeated for Direct Input 21
Table B–9: MODBUS MEMORY MAP (Sheet 52 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
