GE Multilin G60 Generator Protection System B-61
APPENDIX B B.4 MEMORY MAPPING
B
CADB Direct Input/Output Channel 2 CRC Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CADC Reserved (4 items) 1 to 1000 --- 1 F001 10
CAE0 Direct I/O Ch 1 Unreturned Messages Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAE1 Direct I/O Ch 1 Unreturned Messages Alarm Msg Count 100 to 10000 --- 1 F001 600
CAE2 Direct I/O Ch 1 Unreturned Messages Alarm Threshold 1 to 1000 --- 1 F001 10
CAE3 Direct I/O Ch 1 Unreturned Messages Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CAE4 Reserved (4 items) 1 to 1000 --- 1 F001 10
CAE8 Direct IO Ch 2 Unreturned Messages Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAE9 Direct I/O Ch 2 Unreturned Messages Alarm Msg Count 100 to 10000 --- 1 F001 600
CAEA Direct I/O Ch 2 Unreturned Messages Alarm Threshold 1 to 1000 --- 1 F001 10
CAEB Direct I/O Channel 2 Unreturned Messages Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CAEC Reserved (4 items) --- --- 1 F001 10
Remote Devices (Read/Write Setting) (16 modules)
CB00 Remote Device 1 GSSE/GOOSE Application ID --- --- --- F209 “Remote Device 1“
CB21 Remote Device 1 GOOSE Ethernet APPID 0 to 16383 --- 1 F001 0
CB22 Remote Device 1 GOOSE Dataset 0 to 16 --- 1 F184 0 (Fixed)
CB23 Remote Device 1 in PMU Scheme 0 to 1 --- 1 F126 0 (No)
CB24 ...Repeated for Device 2
CB48 ...Repeated for Device 3
CB6C ...Repeated for Device 4
CB90 ...Repeated for Device 5
CBB4 ...Repeated for Device 6
CBD8 ...Repeated for Device 7
CBFC ...Repeated for Device 8
CC20 ...Repeated for Device 9
CC44 ...Repeated for Device 10
CC68 ...Repeated for Device 11
CC8C ...Repeated for Device 12
CCB0 ...Repeated for Device 13
CCD4 ...Repeated for Device 14
CCF8 ...Repeated for Device 15
CD1C ...Repeated for Device 16
Remote Inputs (Read/Write Setting) (64 modules)
CFA0 Remote Input 1 Device 1 to 16 --- 1 F001 1
CFA1 Remote Input 1 Item 0 to 64 --- 1 F156 0 (None)
CFA2 Remote Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
CFA3 Remote Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
CFA4 Remote Input 1 Name 1 to 64 --- 1 F205 “Rem Ip 1”
CFAA ...Repeated for Remote Input 2
CFB4 ...Repeated for Remote Input 3
CFBE ...Repeated for Remote Input 4
CFC8 ...Repeated for Remote Input 5
CFD2 ...Repeated for Remote Input 6
CFDC ...Repeated for Remote Input 7
CFE6 ...Repeated for Remote Input 8
CFF0 ...Repeated for Remote Input 9
CFFA ...Repeated for Remote Input 10
D004 ...Repeated for Remote Input 11
D00E ...Repeated for Remote Input 12
D018 ...Repeated for Remote Input 13
D022 ...Repeated for Remote Input 14
D02C ...Repeated for Remote Input 15
D036 ...Repeated for Remote Input 16
D040 ...Repeated for Remote Input 17
Table B–9: MODBUS MEMORY MAP (Sheet 54 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
