GE Multilin g60

GE Multilin G60 Generator Protection System B-65
APPENDIX B B.4 MEMORY MAPPING
B
D3AC ...Repeated for Remote Device 12
D3B0 ...Repeated for Remote Device 13
D3B4 ...Repeated for Remote Device 14
D3B8 ...Repeated for Remote Device 15
D3BC ...Repeated for Remote Device 16
D3C0 ...Repeated for Remote Device 17
D3C4 ...Repeated for Remote Device 18
D3C8 ...Repeated for Remote Device 19
D3CC ...Repeated for Remote Device 20
D3D0 ...Repeated for Remote Device 21
D3D4 ...Repeated for Remote Device 22
D3D8 ...Repeated for Remote Device 23
D3DC ...Repeated for Remote Device 24
D3E0 ...Repeated for Remote Device 25
D3E4 ...Repeated for Remote Device 26
D3E8 ...Repeated for Remote Device 27
D3EC ...Repeated for Remote Device 28
D3F0 ...Repeated for Remote Device 29
D3F4 ...Repeated for Remote Device 30
D3F8 ...Repeated for Remote Device 31
D3FC ...Repeated for Remote Device 32
Phasor Measurement Unit Communication (Read/Write Setting)
D715 PMU 1 Port 2 D-CH-x Normal State (16 items) 0 to 1 --- 1 F108 0 (Off)
D725 PMU 1 Port 3 D-CH-x Normal State (16 items) 0 to 1 --- 1 F108 0 (Off)
Phasor Measurement Unit Recording Command (Read/Write Command)
E4D4 PMU 1 Recording Clear Command 0 to 1 --- 1 F126 0 (No)
E4D5 PMU 1 Recording Force Trigger 0 to 1 --- 1 F126 0 (No)
Phasor Measurement Unit Recording (Read/Write Setting)
E4DC PMU 1 Record Function 0 to 1 --- 1 F102 0 (Disabled)
E4DD Reserved --- --- 1 F001 0
E4DE PMU 1 No Of Timed Records 1 to 128 --- 1 F001 3
E4DF PMU 1 Trigger Mode 0 to 1 --- 1 F542 0 (Auto Overwrite)
E4E0 PMU 1 Timed Trigger Position 1 to 50 % 1 F001 10
E4E1 Reserved --- --- 1 F001 0
E4E2 PMU 1 Record PHS-1 (14 items) 0 to 14 --- 1 F543 1 (Va)
E4F0 PMU 1 Record PHS-x Name (14 items) --- --- --- F203 GE-UR-PMU-PHS 1
E560 PMU 1 Record A-CH-x (8 items) 0 to 65535 --- 1 F600 0
E568 PMU 1 Record A-CH-x Name (8 items) --- --- --- F203 AnalogChannel 1
E5A8 PMU 1 Record D-CH-x (16 items) 0 to 65535 --- 1 F300 0
E5B8 PMU 1 Record D-CH-x Name (16 items) --- --- --- F203 Dig Channel 1
Phasor Measurement Unit Frequency Trigger (Read/Write Setting)
EB00 PMU 1 Frequency Trigger Function 0 to 1 --- 1 F102 0 (Disabled)
EB01 PMU 1 Frequency Trigger Low Frequency 20 to 70 Hz 0.01 F001 4900
EB02 PMU 1 Frequency Trigger High Frequency 20 to 70 Hz 0.01 F001 6100
EB03 PMU 1 Frequency Trigger Pickup Time 0 to 600 s 0.01 F001 10
EB04 PMU 1 Frequency Trigger Dropout Time 0 to 600 s 0.01 F001 100
EB05 PMU 1 Frequency Trigger Block (3 items) 0 to 65535 --- 1 F300 0
EB08 PMU 1 Frequency Trigger Target 0 to 2 --- 1 F109 0 (Self-reset)
EB09 PMU 1 Frequency Trigger Events 0 to 1 --- 1 F102 0 (Disabled)
Setting file template values (read only)
ED00 FlexLogic™ displays active 0 to 1 --- 1 F102 1 (Enabled)
ED01 Reserved (6 items) --- --- --- --- ---
ED07 Last settings change date 0 to 4294967295 --- 1 F050 0
ED09 Template bitmask (750 items) 0 to 65535 --- 1 F001 0
Table B–9: MODBUS MEMORY MAP (Sheet 58 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
