GE Multilin g60

GE Multilin G60 Generator Protection System B-69
APPENDIX B B.4 MEMORY MAPPING
B
F124
ENUMERATION: LIST OF ELEMENTS
bitmask element
0 Phase Instantaneous Overcurrent 1
1 Phase Instantaneous Overcurrent 2
2 Phase Instantaneous Overcurrent 3
3 Phase Instantaneous Overcurrent 4
4 Phase Instantaneous Overcurrent 5
5 Phase Instantaneous Overcurrent 6
6 Phase Instantaneous Overcurrent 7
7 Phase Instantaneous Overcurrent 8
8 Phase Instantaneous Overcurrent 9
9 Phase Instantaneous Overcurrent 10
10 Phase Instantaneous Overcurrent 11
11 Phase Instantaneous Overcurrent 12
16 Phase Time Overcurrent 1
17 Phase Time Overcurrent 2
18 Phase Time Overcurrent 3
19 Phase Time Overcurrent 4
20 Phase Time Overcurrent 5
21 Phase Time Overcurrent 6
24 Phase Directional Overcurrent 1
25 Phase Directional Overcurrent 2
32 Neutral Instantaneous Overcurrent 1
33 Neutral Instantaneous Overcurrent 2
34 Neutral Instantaneous Overcurrent 3
35 Neutral Instantaneous Overcurrent 4
36 Neutral Instantaneous Overcurrent 5
37 Neutral Instantaneous Overcurrent 6
38 Neutral Instantaneous Overcurrent 7
39 Neutral Instantaneous Overcurrent 8
40 Neutral Instantaneous Overcurrent 9
41 Neutral Instantaneous Overcurrent 10
42 Neutral Instantaneous Overcurrent 11
43 Neutral Instantaneous Overcurrent 12
48 Neutral Time Overcurrent 1
49 Neutral Time Overcurrent 2
50 Neutral Time Overcurrent 3
51 Neutral Time Overcurrent 4
52 Neutral Time Overcurrent 5
53 Neutral Time Overcurrent 6
56 Neutral Directional Overcurrent 1
57 Neutral Directional Overcurrent 2
60 Negative Sequence Directional Overcurrent 1
61 Negative Sequence Directional Overcurrent 2
64 Ground Instantaneous Overcurrent 1
65 Ground Instantaneous Overcurrent 2
66 Ground Instantaneous Overcurrent 3
67 Ground Instantaneous Overcurrent 4
68 Ground Instantaneous Overcurrent 5
69 Ground Instantaneous Overcurrent 6
70 Ground Instantaneous Overcurrent 7
71 Ground Instantaneous Overcurrent 8
72 Ground Instantaneous Overcurrent 9
73 Ground Instantaneous Overcurrent 10
74 Ground Instantaneous Overcurrent 11
75 Ground Instantaneous Overcurrent 12
80 Ground Time Overcurrent 1
81 Ground Time Overcurrent 2
82 Ground Time Overcurrent 3
83 Ground Time Overcurrent 4
84 Ground Time Overcurrent 5
85 Ground Time Overcurrent 6
86 Restricted Ground Fault 1
87 Restricted Ground Fault 2
88 Restricted Ground Fault 3
89 Restricted Ground Fault 4
90 Restricted Ground Fault 5
91 Restricted Ground Fault 6
101 Opposite Phase Rotation
125 Generator Unbalance
140 Auxiliary Undervoltage 1
144 Phase Undervoltage 1
145 Phase Undervoltage 2
148 Auxiliary Overvoltage 1
152 Phase Overvoltage 1
154 Compensated Overvoltage 1
156 Neutral Overvoltage 1
160 Phase Distance Zone 1
161 Phase Distance Zone 2
162 Phase Distance Zone 3
190 Power Swing Detect
210 Volt per Hertz 1
211 Volt per Hertz 2
214 Sensitive Directional Power 1
215 Sensitive Directional Power 2
221 100% Stator Ground
222 Split Phase Protection
224 SRC1 VT Fuse Failure
225 SRC2 VT Fuse Failure
226 SRC3 VT Fuse Failure
227 SRC4 VT Fuse Failure
228 SRC5 VT Fuse Failure
229 SRC6 VT Fuse Failure
265 Stator Differential
296 Accidental Energization
300 Loss Of Excitation
311 Phasor measurement unit one-shot
312 Synchrocheck 1
313 Synchrocheck 2
330 Third harmonic neutral undervoltage
336 Setting Group
337 Reset
344 Overfrequency 1
345 Overfrequency 2
bitmask element
