GE Multilin G60 Generator Protection System B-77
APPENDIX B B.4 MEMORY MAPPING
B
F205
TEXT12: 12-CHARACTER ASCII TEXT
F206
TEXT6: 6-CHARACTER ASCII TEXT
F207
TEXT4: 4-CHARACTER ASCII TEXT
F208
TEXT2: 2-CHARACTER ASCII TEXT
F213
TEXT32: 32-CHARACTER ASCII TEXT
F220
ENUMERATION: PUSHBUTTON MESSAGE PRIORITY
F222
ENUMERATION: TEST ENUMERATION
0 = Test Enumeration 0, 1 = Test Enumeration 1
F224
ENUMERATION: RATE TREND FOR FREQ RATE OF CHANGE
0 = Increasing, 1 = Decreasing, 2 = Bidirectional
F225
ENUMERATION: SPLIT PHASE PROTECTION MODE
0 = Over, 1 = Over-Under
F226
ENUMERATION: REMOTE INPUT/OUTPUT TRANSFER
METHOD
0 = None, 1 = GSSE, 2 = GOOSE
F227
ENUMERATION: RELAY SERVICE STATUS
0 = Unknown, 1 = Relay In Service, 2 = Relay Out Of Service
F230
ENUMERATION: DIRECTIONAL POLARIZING
0 = Voltage, 1 = Current, 2 = Dual
F231
ENUMERATION: POLARIZING VOLTAGE
0 = Calculated V0, 1 = Measured VX
F232
ENUMERATION: CONFIGURABLE GOOSE DATASET ITEMS
FOR TRANSMISSION
value priority
0Disabled
1 Normal
2 High Priority
value GOOSE dataset item
0None
1 GGIO1.ST.Ind1.q
2 GGIO1.ST.Ind1.stVal
3 GGIO1.ST.Ind2.q
4 GGIO1.ST.Ind2.stVal

255 GGIO1.ST.Ind128.q
256 GGIO1.ST.Ind128.stVal
257 MMXU1.MX.TotW.mag.f
258 MMXU1.MX.TotVAr.mag.f
259 MMXU1.MX.TotVA.mag.f
260 MMXU1.MX.TotPF.mag.f
261 MMXU1.MX.Hz.mag.f
262 MMXU1.MX.PPV.phsAB.cVal.mag.f
263 MMXU1.MX.PPV.phsAB.cVal.ang.f
264 MMXU1.MX.PPV.phsBC.cVal.mag.f
265 MMXU1.MX.PPV.phsBC.cVal.ang.f
266 MMXU1.MX.PPV.phsCA.cVal.mag.f
267 MMXU1.MX.PPV.phsCA.cVal.ang.f
268 MMXU1.MX.PhV.phsA.cVal.mag.f
269 MMXU1.MX.PhV.phsA.cVal.ang.f
270 MMXU1.MX.PhV.phsB.cVal.mag.f
271 MMXU1.MX.PhV.phsB.cVal.ang.f
272 MMXU1.MX.PhV.phsC.cVal.mag.f
273 MMXU1.MX.PhV.phsC.cVal.ang.f
274 MMXU1.MX.A.phsA.cVal.mag.f
275 MMXU1.MX.A.phsA.cVal.ang.f
276 MMXU1.MX.A.phsB.cVal.mag.f
277 MMXU1.MX.A.phsB.cVal.ang.f
278 MMXU1.MX.A.phsC.cVal.mag.f
279 MMXU1.MX.A.phsC.cVal.ang.f
280 MMXU1.MX.A.neut.cVal.mag.f
281 MMXU1.MX.A.neut.cVal.ang.f
282 MMXU1.MX.W.phsA.cVal.mag.f
283 MMXU1.MX.W.phsB.cVal.mag.f
284 MMXU1.MX.W.phsC.cVal.mag.f
285 MMXU1.MX.VAr.phsA.cVal.mag.f
286 MMXU1.MX.VAr.phsB.cVal.mag.f
287 MMXU1.MX.VAr.phsC.cVal.mag.f
288 MMXU1.MX.VA.phsA.cVal.mag.f
289 MMXU1.MX.VA.phsB.cVal.mag.f
290 MMXU1.MX.VA.phsC.cVal.mag.f
291 MMXU1.MX.PF.phsA.cVal.mag.f
292 MMXU1.MX.PF.phsB.cVal.mag.f
