CHAPTER 7: SPECIFICATIONS TESTING AND CERTIFICATION
MM300 MOTOR MANAGEMENT SYSTEM – QUICKSTART GUIDE 7
Testing and certification
EAC
The EAC Technical Regulations (TR) for Machines and Equipment apply to the Customs
Union (CU) of the Russian Federation, Belarus, and Kazakhstan
TESTING AND CERTIFICATION
Test Reference Standard Test Level
Dielectric Voltage Withstand: EN60255-5 2.3KV (1 minute)
Impulse Voltage Withstand: EN60255-5 5KV
Damped Oscillatory: IEC61000-4-18IEC60255-22-1 2.5KV CM, 1KV DM
Electrostatic Discharge: EN61000-4-2/IEC60255-22-2 Level 4
RF Immunity: EN61000-4-3/IEC60255-22-3 Level 3
Fast Transient Disturbance: EN61000-4-4/IEC60255-22-4 Class A
Surge Immunity: EN61000-4-5/IEC60255-22-5 Level 3
Conducted RF Immunity: EN61000-4-6/IEC60255-22-6 Level 3
Voltage Interruption and Ripple DC: IEC60255-11 15% ripple , 200ms
interupts
Radiated & Conducted Emissions: CISPR11 /CISPR22/ IEC60255-25 Class A
Sinusoidal Vibration: IEC60255-21-1 Class 1
Shock & Bump: IEC60255-21-2 Class 1
Power magnetic Immunity: IEC61000-4-8 Level 5
Pulse Magnetic Immunity: IEC61000-4-9 Level 4
Voltage Dip & Interruption: IEC61000-4-11 0,40,70% dips,250/300cycle
interrupts
Damped Oscillatory: IEC61000-4-12 2.5KV CM, 1KV DM
Harmonics & Interharmonics: IEC61000-4-13 Class 3
Voltage Ripple: IEC61000-4-17 15% ripple
Ingress Protection: IEC60529 IP20 (base unit) , IP54
(Control Panel)
Environmental (Cold): IEC60068-2-1 -25
o
C 16 hrs
Environmental (Dry heat): IEC60068-2-2 70
o
C 16hrs
Relative Humidity Cyclic: IEC60068-2-30 6-day variant 2
APPROVALS
Applicable Council Directive According to
CE compliance: Low voltage directive EN60255-5, EN61010-1
EMC Directive EN50263 / EN61000-6-2/ EN61000-6-4
North America: cULus UL1053 [e83849 NKCR]
UL508 [e83849 NKCR]
C22.2-14 [e83849 NKCR7]
EAC Machines and Equipment TR CU 010/2011
ISO: Manufactured under a registered
quality program
ISO9001
