MM300 MOTOR MANAGEMENT SYSTEM – QUICKSTART GUIDE 1
MM300 Motor Management System
Chapter 8: MM300 order codes
GE
Grid Solutions
MM300 order codes
The information to specify an MM300 relay is provided in the following order code figure.
Figure 8-1: MM300 order codes
853702A4.PDF
NOTES:
*
The UV Restart feature is not supported with the Low-Voltage power supply option.
Harsh Environment Coating is a standard feature on all MM300 units.
Base Expanded
MM300 * E * * * * A * * * *
InterfaceMM300 | |||| |||| MM300 Motor Management System
Control
panel
X | | | | | | | | No control panel
B | | | | | | | | Basic control panel, no USB
G | | | | | | | | Graphical control panel with USB
Power supply H | | | | | | | High: 80 to 250 V DC (Standard); 60 to 300 V AC
L | | | | | | | Low*: 24 V DC (24 to 48 V DC Nominal)
Communications S|| |||| Standard communications: RS485 Modbus RTU
D|| |||| Standard plus DeviceNet Slave and 10/100 Modbus TCP
P|| |||| Standard plus Profibus DP Slave and 10/100 Modbus TCP
Options S | | | | | Standard: Starter control and event recorder
1 | | | | | Option 1: Standard plus undervoltage autorestart
2 | | | | | Option 2: Option 1 plus waveform capture and data logger
3 | | | | | Option 3: Option 2 plus FlexLogic
Protection | XXXX No Additional Protection
|
|
B
|
|
|
|
|
|
Three-phase voltage metering and three-phase underpower,
undervoltage, overvoltage, phase reversal
| GGGG Bank of three (3) RTDs: 100PT (maximum of 2 banks)
Input/output modules C C C C C Two (2) 10 A form-A relays and six (6) 60 to 300 V AC digital Inputs
E E E E E Two (2) 10 A form-A relays and six (6) 20 to 60 V DC digital Inputs
D D D D Four (4) 10 A form-C relays
