18 MM300 MOTOR MANAGEMENT SYSTEM – QUICKSTART GUIDE
INTERFACING WITH THE MM300 CHAPTER 2: INSTALLATION
2. Visual verification of active alarms, relay display messages, and LED indications.
3. Visual inspection for any damage, corrosion, dust, or loose wires.
4. Event recorder file download with further events analysis.
Out-of-service maintenance
1. Check wiring connections for firmness.
2. Analog values (currents, voltages, RTDs, analog inputs) injection test and metering
accuracy verification. Calibrated test equipment is required.
3. Protection elements setting verification (analog values injection or visual verification
of setting file entries against relay settings schedule).
4. Contact inputs and outputs verification. This test can be conducted by direct change
of state forcing or as part of the system functional testing.
5. Visual inspection for any damage, corrosion, or dust.
6. Event recorder file download with further events analysis.
FAST PATH:
To avoid deterioration of electrolytic capacitors, power up units that are stored in a de-
energized state once per year, for one hour continuously.
Unscheduled maintenance (system interruption)
• View the event recorder and oscillography for correct operation of inputs, outputs,
and elements.
Interfacing with the MM300
There are three methods of interfacing with the MM300 Motor Management System.
• Interfacing via the graphical control panel.
• Interfacing via the basic control panel.
• Interfacing via the EnerVista MM300 Setup software.
This section provides an overview of the interfacing methods available with the MM300
using the Graphical and Basic control panels. For additional details on interface
parameters (for example, settings, actual values, etc.), refer to the individual chapters.
MM300 graphical display pages
A summary of the MM300 page hierarchy is shown below.
