MM300 MOTOR MANAGEMENT SYSTEM – QUICKSTART GUIDE 1
MM300 Motor Management System
Chapter 2: Installation
GE
Grid Solutions
Instal lation
Mechanical installation
This section describes the mechanical installation of the MM300 system, including
dimensions for mounting and information on module withdrawal and insertion.
Dimensions
The MM300 is packaged in a modular arrangement.
The dimensions of the MM300 are shown below. Additional dimensions for mounting and
panel cutouts are shown in the following sections.
