6 MM300 MOTOR MANAGEMENT SYSTEM – QUICKSTART GUIDE
POWER SUPPLY SPECIFICATIONS CHAPTER 7: SPECIFICATIONS
Power supply specifications
POWER SUPPLY (HIGH PSU)
Nominal:.................................................................. 120 to 240 V AC 125 to 250 V DC
Range:...................................................................... 60 to 300 V AC (50 and 60 Hz) 84 to 250 V DC
Ride-Through:....................................................... 35 ms
POWER SUPPLY (LOW PSU)
Nominal:.................................................................. 24 to 48 V DC
Range:...................................................................... 20 to 60 V DC
Ride-Through:....................................................... 35 ms
ALL RANGES
Voltage withstand: ............................................. 2 × highest nominal voltage for 10 ms
Power consumption: ......................................... 16 W typical, 25 W maximum
Communications specifications
DEVICENET (COPPER)
Modes: ..................................................................... slave (125, 250, and 500 kbps)
Connector: ............................................................. 5-pin terminal
Current Draw:....................................................... 80 mA @ 24 VDC
ETHERNET (COPPER)
Modes: ..................................................................... 10/100 MB (auto-detect)
Connector: ............................................................. RJ-45
SNTP clock synchronization error:.............. <200 ms (typical)
Protocol:.................................................................. Modbus TCP
PROFIBUS (COPPER)
Modes: ..................................................................... DPV0 slave, up to 1.5 Mbps DPV1 slave, up to 1.5 Mbps
Connector: ............................................................. 5-pin terminal
RS485 PORT
Port:........................................................................... opto-isolated
Baud rates: ............................................................ up to 115 kbps
Protocol:.................................................................. Modbus RTU, half-duplex
Maximum distance:........................................... 1200 m
Isolation: ................................................................. 2 kV
USB PORT (GRAPHIC CONTROL PANEL ONLY)
Standard specification:.................................... Compliant with both USB 2.0 and USB 1.1
Data transfer rate: ............................................. USB device emulating serial communications port at 115
kbps
