8 MM300 MOTOR MANAGEMENT SYSTEM – QUICKSTART GUIDE
PHYSICAL SPECIFICATIONS CHAPTER 7: SPECIFICATIONS
Physical specifications
DIMENSIONS
Size: ........................................................................... Base: 120 mm (W) × 90 mm (H) × 113 mm (D) [+ terminals
10mm]
Expansion: 62 mm (W) × 90 mm (H) × 113 mm (D)
GCP: 153 mm (W) × 102 mm (H) × 35 mm (D)
BCP: 75 mm (W) × 75 mm (H) × 31 mm (D)
Weight (Base):....................................................... 0.75 kg
Environmental specifications
Item Description
Country of origin Spain or Canada; see label on the unit
Date of manufacture See label on the MM300 unit
Declaration of Conformity and/or Certificate of
Conformity
Available on request
ENVIRONMENTAL SPECIFICATIONS
Ambient temperatures:
Storage/shipping: - 40
o
C to 90
o
C *
Operating: -20
o
C to 60
o
C *
* 1" around Base Unit
Humidity: Operating up to 95% (non condensing) @ 55
o
C (As
per IEC60068-2-30 Variant 2, 6days)
Altitude: 2000m (max)
Overvoltage Category: II
Ingress Protection: IP20 (Base Unit) IP54 (Control Panel)
Environmental rating: 60
o
C surrounding air
Pollution Degree: II
Type 1 (panel mount versions only)
Noise: 0 dB
