MM300 MOTOR MANAGEMENT SYSTEM – QUICKSTART GUIDE 1
MM300 Motor Management System
Chapter 4: Setpoints
GE
Grid Solutions
Setpoint s
Understanding setpoints
Any of the motor trip and alarm setpoints may be viewed or altered by pressing the
Setpoints soft-key. Setpoints data is divided into four pages.
Configuration page: Information about the motor configuration as well as system
setup, inputs, outputs, communications, CTs, and VTs.
Protection page: Information about the protection features.
Control page: Information about the process control features.
Security page: Information about the security and password features.
Press the Setpoint soft-key to scroll through the setpoints pages. When pressed for the
first time, the following screen is displayed.
Figure 4-1: Setpoints home page
The soft-keys on the Home > Setpoints page open pages two levels down, since the pages
immediately below this page are blank. For example, the Config soft-key opens the Home
> Setpoints > Config > Motor page.
