GE NX-10 Installer Manual

Shipping weight 441 g
NX-1048-W LCD keypad (wired)
Power supply specifications
Power supply voltage
9 V … 14.4 V  ± 2%
Current consumption – backlight ON, buzzer ON
35.0 mA at 13.8 V  ± 5%
Current consumption – backlight ON, buzzer OFF
28.9 mA at 13.8 V  ± 5%
Current consumption – standby
13.8 mA at 13.8V  ± 5%
General feature specifications
PCB Size
Dimensions (width x height x depth) 158 x 88 x 1.2 mm
Housing Size
Dimensions (width x height x depth) 178 x 102 x 20 mm
Environmental
Operating temperature -10 °C to +55 °C
Humidity Max 95%, non condensing
Shipping weight 227 g
