Page #235 background imageLoading...
Page #235 background image
NX-10 Installers manual
235
6. Select the location in the NX586E from which the data will be retrieved.
7. A screen will appear indicating that the data is being read. When this screen disappears,
the process is complete.
Location programming for the NX-586E
The only location used on the NX-586E is location 0. The seven segments have the following
functions and meaning:
Table 35.
Segment 1 Used to set the task to perform (read or write) and display the result of the task requested.
0 = Idle condition
1 = Read
p
anel confi
g
uration into a file COMMAND
2 = Write a file’s confi
g
uration into the
p
anel COMMAND
10 = Workin
g
RESULT
11 = Invalid command
;
installer entered a value other than 1 or 2 RESULT
12 = Invalid file number
;
installer entered a file number other than 1-4 RESULT
13 = Incorrect
p
anel t
yp
e
;
the
p
anel and file t
yp
es do not match RESULT
14 = Incorrect access code
;
the
p
anel and file access code do not match RESULT
15 = Timeout
;
the re
q
uested command had no data exchan
g
e for 3 seconds RESULT
16 = Aborted
;
the
p
revious command was aborted b
y
attem
p
tin
g
another command RESULT
20= Transfer successful
;
the
p
revious read or write command was successful RESULT
Segment 2
Used to hold the file number for the requested read or write command. The only valid values are 1-4. This
segment is always set to 0 after any command to prevent accidentally overwriting an incorrect file.
Segments
3 - 6
Used to indicate the panel type stored in files 1-4 respectively.
Results 1 - 3 applies to the standard NetworX panels (NX-4 / NX-6 / NX-8).
Result 4 applies to the NX-8E panel.
Result 10 applies to the NX-4V2 panel
Result 11 applies to the NX-6V2 panel
Result 12 applies to the NX-8V2 panel
Result 15 applies to NX-10 panel.
Segment 7
Used to set the baud rate for the RS-232 connection (must match that of the DL-900 program). The valid
values are 0-7 and will be reset to 4 (9600 baud - factory default) if set incorrectly.
0= 600 Baud 2= 2400 Baud (2.4K) 4= 9600 Baud (9.6K) 6= 38400 Baud (38.4K)
1= 1200 Baud (1.2K) 3= 4800 Baud (4.8K) 5= 19200 Baud (19.2K) 7= 76800 Baud (76.8K)
Glossary
Location Term Definition
13 NX-586E A menu optional device used to interface the up/download
software directly to the control panel when the on board
serial port is not available.
13.1 Files A menu entry that groups the four programming memories
in the direct connect module.
13.1.1 File 1 A menu option that selects the programming memories
within the direct connect module. There are four possible
programming memories.
