Data Event Data Event
25 Fire 55 Auxiliary communication failure
26 Fire trouble 56 Radio test
27 Chime 57 Any siren when armed in any mode
28 Expander trouble 58 Alarm memory (pulsating)
29 Dynamic battery test time 59 Zone inactivity

If set to follow condition, these events are one second
.
Note: When Event 48 is programmed, it is possible to program a user code's authorization to select which output(s)
a particular code activates.
Configuring the internal siren
You can specify conditions and/or events that activate the internal siren. To configure the internal
siren, you must enable the advanced menu. The following example configures a short blast of the
internal siren when the system is armed using a keyswitch.
1. Ensure the advanced menu is enabled.
2. Navigate with the ½¾ keys to Control Panel>Outputs>Internal Siren>Short Blast On
and press OK.
3. Scroll to Keyswitch Arming>Yes and press OK.
4. The keypad beeps once to confirm the change and returns to Keyswitch Arming.
Programming the keypad sounder
You can specify conditions and/or events that activate the keypad sounder. To configure the sounder,
you must enable the advanced menu. The following example programs the keypad sounder to
activate when an expander trouble condition occurs.
1. Ensure the advanced menu is enabled.
2. Navigate with the ½¾ keys to Control Panel>Outputs>Keypads>Sound On and press
OK.
3. Scroll to Expander Trouble>Enabled and press OK.
4. The keypad beeps once to confirm the change and returns to Expander Trouble.
Assigning codes
Figure 15. Installer codes menu
System codes can be either four or six digits long. This menu allows to program/change the installer
code and the duress code. A duress code disarms the system and activates a duress alarm. This is a
Duress Code
Guard Codes 16 17
User Auth for Pro
To Next Page
