8
Battery low
This icon is only available on the wireless keypad and flashing when the
keypad battery is low.
9
Alarm
This icon flashes in case of an alarm condition.
10
This icon is only available on the wireless keypad and indicates RF-link
field strength. The one most to the left indicates absence of RF, the one
most to the right indicates full signal strength. It will flash as long as the
keypad is not registered yet.
11
Trouble
This icon indicates a system trouble condition, for example, fire trouble,
day zone trouble or AC power loss. You can display the trouble list by
pressing the # (hash) button on the keypad (see
Appendix 4: Service
messages on page
251.)
12
Service
This icon is ON in case the system needs to be serviced. It can indicate
many conditions, for example, ground fault, phone fault, fail to
communicate, box tamper, loss of system time, and similar problems. You
can display the service message list by pressing the # (hash) button on the
keypad (see
Appendix 4: Service messages on page 251.)
13
Ready to arm
If the system is OK to arm, the V-sign icon is displayed. If it is NOT OK to
arm, the V-sign disappears. In case a force armable zone is open, it will
show a flashing V-sign (see Table 11 Default zone
types, and Force
Armable menu option description in the glossary.)
