TX-7001-05-1 Wireless indoor siren specifications
Power supply specifications
Number and type of batteries 4 x AA size, 1.5 V, primary cell
Battery capacity 5600 mAh
Electronics
Board operating voltage 2.1 V … 3.1 V
Number and type of batteries 1 x 9V size block, primary cell
Battery capacity 600 mAh
Siren part
Operating voltage 9 V … 12 V
Battery lifetime (typical) 3 years *
Current consumption – IO module (typical) 160 uA at 3.1 V ± 5%
Current consumption – siren (typical) 105 mA at 12 V ± 5%
General feature specifications
Operating temperature -10 °C to +40 °C
Humidity max 95%, non condensing
Environmental
Shipping weight 470 g
* Assumption: maximum 20 siren activations of 3 minutes per year.
Wireless I/O module specifications
Power supply specifications
Number and type of batteries 4 x AA size, 1.5 V, primary cell
Battery capacity 5600 mAh
Board operating voltage 2.1 V … 3.1 V
Battery lifetime, typical 3 years
Current consumption 160 uA at 3.1 V ± 5%
General feature specifications
Number, type and rating of outputs 2 x O/C, 15 V / 3 A max
Number and range of inputs (if wire jumper cut) 1 x, range 0 V … +15 V
Operating temperature -10 °C to +55 °C
Humidity max 95%, non condensing
Environmental
Shipping weight 96 g
