3.3 Mounting Requirements
3.3.1 Floor Loading and Recommended Mounting Methods
See Table 2-7. To obtain floor loading and recommended mounting methods for components
not specified in Table 2-7, refer to the appropriate component Pre-Installation Manual listed in
Basic System Compatibility.
Table 2-7:
PRODUCT OR
COMPONENT
NET WEIGHT
KG (LBS)
DIMENSIONS MM (INCHES) LOAD BEAR‐
ING AREA
MM (IN‐
CHES)
WEIGHT/ OC‐
CUPIED
AREA
MOUNTING METHOD
WIDTH DEPTH HEIGHT
LC Positioner 750 (1655) See Illustrations
LC POSITIONER DI‐
MENSIONS :
•
Side view
•
Top view
•
Front view
in Dimension Drawings
Circle diame‐
ter 600
(23.62)
Recommended:
•
Through-Bolts
(12)
Alternates:
•
On Grade 5/8 in,
Anchors (12)
•
Above Grade 3/4
in. Anchors (12)
See Illustration 2-58,Il‐
lustration 2-59 and Il‐
lustration 2-60
Table 590 (1300)
See note 1
See illustrations in Dimension Draw‐
ings
•
Omega IV
•
Omega V
571.5x429
(22.5x16.9)
2410 kg/m
2
(492.3 lb/ft
2
)
Same as LC Position‐
er See IMPORTANT
NOTICE below.
System Control
Cabinet
See Illustration
System Control Cabi‐
net Dimensions in Dimension Draw‐
ings
1206x717(47.
5x28.2)
740 kg/m
2
(152 lb/ft
2
)
COOLIX 4100 120 (264.5) 555 (21.8) 610 (24) 1200 (47.2)
Autotransformer
(Coolix 4100)
30 (66) 370 (14.5) 304 (12) 340 (13.4)
Detector Chiller
Thermo-Con
14.6 ( 32.2)
See Illustration Detector Chiller Ther‐
mo–Con Dimensions in Dimension
Drawings
344x283
(13.5x11.14)
Fluoro UPS UL
(optional)
530 (1169) 690 (27.0) 800 (31.5) 1820 (70.1)
975 kg/m
2
(200 lb/ft
2
)
Ground -mounted
Fluoro UPS CE
(optional)
480 (1059) 680 (26.7) 800 (31.5) 1450 (57.1)
883 kg/m
2
(181 lb/ft
2
)
Ground -mounted
Fluoro UPS IF box
(optional)
4 (9) 280 (11.02)
314
(12.36)
124.5 (4.9) Wall-mounted
PDB US (4) 148 (326) 685 (27) 225 (9) 1850 (73) Wall-mounted
PDB CE (4) 110 (242) 800 300 1200 Wall-mounted
EMI Filter enclo‐
sure CE (4)
<40 300 210 950 Wall-mounted
DL keypad 1.4 (3) 283 (11.55) 300 (11.8) 82 (3.25)
