For the tables below, refer to Illustration 2-38
Note: For Head Extender Dimensional drawing, refer to Dimension Drawings
Table 2-4: Omega IV Table
Configuration
Minimum Room length in mm (inches)
without Head Extender (see note
above)
with Head Extender (see note above)
Cardio 1395 mm (54.9 in)
5470 (215.3) 5470 (215.3)
Table 2-5: Omega V Table
Configuration
Minimum Room length in mm (inches)
without Head Extender
with Head Extender
Angio 1278 mm (50.3 in)
6036 (237.6) 6036 (237.6) + 150 (6)
Cardio and Neuro 1395 mm (54,9 in)
6036 (237.6) 6036 (237.6) + 150 (6)
