GE MEDICAL SYSTEMS PRECISION RXI® AND PRECISION RXI® VERSION E SYSTEM DRAWINGS
DIRECTION 5142538 -100, REVISION 6
Page 14
Inside CONSOLE cables for ANALOG SYSTEM (only for SVGA input monitor
)
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
N09 56220 5130706
Video converter/Monitor
Power Supply
/ /
Console - Totoku power supply ac/dc adaptor
(12Vdc Out)
Console - Nical video converter (12Vdc In) 7 0.28 internal
N10 40533
5130710
Power Supply Monitor / / Console - Nical video converter (12Vdc Out) Console - Totoku power supply (12Vdc In) 7 0.28 internal
N11 56222 5130711 SVGA Monitor - M/M / / Console - Nical video converter - SVGA
Console - Totoku Monitor - video signal input
SVGA
8 0.32 internal
Inside CONSOLE cables for DIGITAL SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
D15 56218 5130712 Power supply PC / / Console - power supply multiple connector Console - PC - power supply (120Vac In) 9 0.35 internal
D16 56218 5130712 Power supply Monitor / / Console - power supply multiple connector
Console - Monitor - power supply
(120Vac In)
9 0.35 internal
D17 56218 5130712 Power supply Modem / / Console - power supply multiple connector
Console - Modem - power supply ac/dc
adaptor (120Vac In)
9 0.35 internal
D18 56224 5130715 Power supply Modem / /
Console - Modem - power supply ac/dc
adaptor (9Vac Out)
Console - Modem - power supply (9Vdc In) 6 0.24 internal
D19 56209 5130716 SVGA Monitor - M/M / / Console - PC o Video Splitter (opz.) - SVGA Console - Monitor SVGA 8 0.32 internal
D20 56216 5130717 Serial RS232 Modem / / Console - PC - serial COM1 Console - Modem - serial 7 0.28 internal
D21
726-521-
G1
5130718 Digital PC DVI / / Console - PC - DVI Console - PC - DVI 7 0.28 internal
D22 56228 N/A Digital PC Keyboard / / Console - keyboard Console - PC - keyboard 4 0.16 internal
D23 56230 N/A Digital PC trackball / / Console - trackball Console - PC - trackball 4 0.16 internal
D42 56467 5142361 Ground Digital PC / / Console - GMM console - Ground Console - PC - Ground 6 0.24 internal
Inside CONSOLE cables for ROOM DIRECT MONITOR by DIGITAL SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
D25 56226 5130721 Power supply Video Splitter / /
Console - Video Splitter ac/dc adaptor (9Vdc
Out)
Console - Video Splitter (9Vdc In) 7 0.28 internal
D26 56210 5130722
SVGA video signal for video
splitter M/F
/ / Console - PC - SVGA
Console -Video Splitter Splitter - SVGA -
M/M
8 0.32 internal
