GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
Page 28 / 111 June 2009
5.2.1.1.2. -30/+90 Non-Elevating Table cont.
1) Integrated console
2) Remote-controlled table
3) Power cabinet for positioner
4) Power cabinet for generator
5) Exam room monitor
SAFETY AREA IN COMPLIANCE
WITH EN 292 RULES
The distance between the table cabinet and the table
cables support can not be more than 7 meters.
The distance between the generator cabinet and the table
cables support can not be more than 5 meters.
