GE MEDICAL SYSTEMS PRECISION RXI SYSTEM PRE-INSTALLATION
D
IRECTION 5123449-100, REVISION 12
_____________________________________________________________________________________________
Page 30 / 111 June 2009
5.2.1.1.4. -30/+90 Non-Elevating Table cont.
Not elevating tables fixation by means of small blocks
Shim
0.5 mm
1.0 mm
1.5 mm
Fig. 1: Shims provided as serial standard accessories
6 shims are provided for each
measure specified in the table. These
are to be used for leveling next to the
special screws.
