GE Proteus XR/a User Manual

PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-4
14-3-2 General Input Power Specifications
TABLE 14-4
MODEL DEPENDENT SPECIFICATIONS
PARAMETER JEDI GENERATOR
Input Voltage
380/400/415/440/460/480VAC three phase and Ground without neutral
Daily Voltage Variations
+/-10% (in this range, the generator shall operate without any derating in
accuracy)
Line Impedance Specification
IEC Specification
Line Impedance
The apparent line impedance guaranteed by the customer should be equal
or less than the values indicated below, according to the voltage value and
the commercial power of the generator
Voltage range(V) line impedance (Ohms)
(3 phase) 32kW 50kW 65kW 80kW
380 0.25 0.15 0.12 0.09
415 0.30 0.18 0.14 0.11
440 0.34 0.20 0.15 0.125
480 0.40 0.24 0.18 0.15
HV cable type
IB EEC: 22mm cable de Lyon (<=150pF/m)
USA: 22mm DSI (<=165pF/m)
EEC: 16mm Claymount (<=165pF/m)
HV cable connector =Federal standard
Ground Wire
Same as power cable
Inrush Current
1000A
Normal Frequency
50/60Hz
Daily Frequency Variation
+/-6%
