PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-5
14-3-3 Generator Output Power:
TABLE 14-5
PROTEUS XR/A GENERATOR POWER
kV 32kW 50kW 65kW 80kW
40-80 400mA 630mA 800 mA 1000 mA
100 320mA 500mA 630 mA 800 mA
125 250mA 400mA 500 mA 630 mA
150 200mA 320mA 400 mA 500 mA
The Proteus XR/a can deliver the power specified in this output for at least
100ms, depending on the X-ray tube used. Refer to the tube rating charts
supplied with the x-ray tube.
In accordance with IEC requirements, Table 14-7 defines the reference Current
Time Product.
TABLE 14-6
NOMINAL ELECTRIC POWER (100kV-0.1S):
KW
k
32 50 65 80
I (max)
mA
320 500 630 800
TABLE 14-7
PARAMETER SELECTION RANGES OF CONSOLE READOUTS
All Modes
Selectable kV
40-150
Decimal scale
steps of 1kV Jump of 10kV
Renard scale
40,41,42,44,46,48,50,52,
55,57,60,63,66,70,73,77,
81,85,90,96,102,109,117,
125,133,141,150
The next kV displayed is
the third Renard step
value following the initial
display value of kV.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
