TABLE 14-9
ACCURACY OF CONSOLE READOUTS
Note: In RAD mode, kVp accuracy is ensured after 10ms.
Displayed before exposure
Conditions parameter mode Basic Accuracy
kVp all +/- ( 3%, + 2 kVp)
Radiography mA all +/- ( 10%, + 1 mA)
Exposure ms 3 point timer +/- ( 5%, + 0.5ms)
Time mAs 2 point +/- (5%, + 0.1 mAs)
< = 40 ms ms AEC (2/3 point) +/- 5%
mAs AEC (2/3 point) +/- 10%
mA AEC (3 point) +/- 15%
Radiography mA all +/- ( 5%, + 1 mA)
Exposure ms 3 point timer +/- ( 5%, + 0.5ms)
Time mAs 2 point +/- (5%, + 0.1 mA)s
> 40 ms ms AEC (2/3 point) +/- 5%
mAs AEC (2/3 point) +/- ( 5%, + 0.1 mAs)
mA AEC (3 point) +/- 10%
14-3-4 Power Line Requirements
See Table 14-10 for 32 kW Three Phase Generators.
See Table 14-12 for 50 kW Three Phase Generators.
See Table 14-14 for 65 kW Three Phase Generators.
See Table 14-16 for 80 kW Three Phase Generators.
TABLE 14-10
MINIMUM WIRE SIZE (32 kW)
PARAMATER THREE PHASE GENERATOR - 32KW
Input Voltage 380VAC 400 VAC 415 VAC 440 VAC 460 VAC 480 VAC
Wire Size
Length
15 m (50 ft.)
10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG)
30 m (100 ft.)
10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG)
46 m (150 ft.)
16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG)
60 m (200 ft.)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
TABLE 14-11
KVA LOAD CHARACTERISTICS 32KW
Phase 3 3 3 3 3 3
Nominal line Voltage(Vac) 380 400 420 440 460 480
Voltage range(Vac)
+/−10% +/−10% +/−10% +/−10% +/−10% +/−10%
Momentary line
current(Amp)
70 66 63 60 58 55
Continuous line
current(Amp)
7 6.7 6.2 6 5.7 5.5
Power demand(kVA) 46 46 46 46 46 46
Frequency 47 /53Hz and 57/63Hz
TABLE 14-12
MINIMUM WIRE SIZE (50 kW)
PARAMATER THREE PHASE GENERATOR - 50KW
Input Voltage 380VAC 400 VAC 415 VAC 440 VAC 460 VAC 480 VAC
Wire Siz
e
Length
15 m (50 ft.) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG) 10 mm2 (#8 AWG)
30 m (100 ft.) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG) 16 mm2 (#6 AWG)
46 m (150 ft.)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
2
2 mm2 (#5 AWG)
60 m (200 ft.)
3
0 mm2 (#3 AWG)
3
0 mm2 (#3 AWG)
3
0 mm2 (#3 AWG)
3
0 mm2 (#3 AWG)
3
0 mm2 (#3 AWG)
3
0 mm2 (#3 AWG)
