PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-8
TABLE 14-13
KVA LOAD CHARACTERISTICS 50KW
Phase 3 3 3 3 3 3
Nominal line Voltage(Vac) 380 400 420 440 460 480
Voltage range(Vac)
+/−10% +/−10% +/−10% +/−10% +/−10% +/−10%
Momentary line
current(Amp)
110 105 100 95 92 88
Continuous line
current(Amp)
7 6.7 6.2 6 5.7 5.5
Power demand(kVA) 70 70 70 70 70 70
Frequency 47 /53Hz and 57/63Hz
TABLE 14-14
MINIMUM WIRE SIZE (65 kW)
PARAMATER THREE PHASE GENERATOR - 65KW
Input Voltage 380VAC 400 VAC 415 VAC 440 VAC 460 VAC 480 VAC
Wire Size
Length
15 m (50 ft.) 16 mm
2
(#6 AWG) 16 mm
2
(#6 AWG) 16 mm
2
(#6 AWG) 16 mm
2
(#6 AWG) 16 mm
2
(#6 AWG) 16 mm
2
(#6 AWG)
30 m (100 ft.)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
46 m (150 ft.)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
60 m (200 ft.)
4
4 mm
2
(#1 AWG)
4
4 mm
2
(#1 AWG)
4
4 mm
2
(#1 AWG)
4
4 mm
2
(#1 AWG)
4
4 mm
2
(#1 AWG)
4
4 mm
2
(#1 AWG)
TABLE 14-15
KVA LOAD CHARACTERISTICS 65KW
Phase 3 3 3 3 3 3
Nominal line voltage (Vac) 380 400 420 440 460 480
Voltage range (Vac)
+/−10% +/−10% +/−10% +/−10% +/−10% +/−10%
Momentary line current
(Amp)
147 140 133 127 122 117
Continuous line current
(Amp)
7 6.7 6.2 6 5.7 5.5
Power demand (kVA) 97 97 97 97 97 97
Frequency 47 /53Hz and 57/63Hz
TABLE 14-16
MINIMUM WIRE SIZE (80 kW)
PARAMATER THREE PHASE GENERATOR - 80KW
Input Voltage 380VAC 400 VAC 415 VAC 440 VAC 460 VAC 480 VAC
Wire Siz
e
Length
15 m (50 ft.)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
2
2 mm
2
(#5 AWG)
30 m (100 ft.)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
3
0 mm
2
(#3 AWG)
46 m (150 ft.)
4
3 mm
2
(#1 AWG)
4
3 mm
2
(#1 AWG)
4
3 mm
2
(#1 AWG)
4
3 mm
2
(#1 AWG)
4
3 mm
2
(#1 AWG)
4
3 mm
2
(#1 AWG)
60 m (200 ft.)
5
4 mm
2
(#0 AWG)
5
4 mm
2
(#0 AWG)
5
4 mm
2
(#0 AWG)
5
4 mm
2
(#0 AWG)
5
4 mm
2
(#0 AWG)
5
4 mm
2
(#0 AWG)
TABLE 14-17
KVA LOAD CHARACTERISTICS 80KW
Phase 3 3 3 3 3 3
Nominal line Voltage (Vac) 380 400 420 440 460 480
Voltage range (Vac)
+/−10% +/−10% +/−10% +/−10% +/−10% +/−10%
Momentary line current
(Amp)
190 180 170 163 156 150
Continuous line current
(Amp)
7 6.7 6.2 6 5.7 5.5
Power demand (kVA) 125 125 125 125 125 125
Frequency 47 /53Hz and 57/63Hz
Note:
Wire size from Distribution Transformer to Disconnect Switch. Voltage is
three-phase measured line to line, balanced to neutral.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
