GE Proteus XR/a User Manual

PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-12
14-6-2 Proteus XR/a Manual Collimator
See Table 14-22.
TABLE 14-22
MANUAL COLLIMATOR ELECTRICAL SPECIFICATIONS
Parameter Specification
Additional prefilter
0, 0.1, 0.2, 0.3 mm Cu
Operation mode
Manual
Radiological Properties
Inherent Filtration 1.0 mm Al with 75 kV
Radiation shielding Max. 150kV
Leakage radiation <50 mR/h (at 150kV/3mA, 1m distance from tube ass.)
Maintenance
Maintenance free
Light Localizer Power
Supply
28 - 40VDC (±10%) / 10A
Mechanical interfaces
Flange to the tube assembly Diameter: 136mm
Thickness: 2mm
Source flange distance 80mm
Accessory rails Number: 2
Width: 178mm
Length: 178mm
Height of the guide: 2mm
Quality standards
CE, UL, CSA, DHHS
Ambient conditions
Temperature range 10°C to 40°C
Rel. humidity: 20 % to 75 %, non-condensing
Barometric pressure: 70 kPa to 106 kPa
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
