GE Proteus XR/a User Manual

PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-13
14-6-3 Eclipse Proteus Collimator Specifications
TABLE 14-23
ECLIPSE PROTEUS COLLIAMTOR ELECTRICAL SPECIFICATIONS
Description Specification
Dimensions (L x W x H) [mm] 330 x 210 x 180
Weight [kg]
10 ± 0,5
Angle of rotation around central beam axis [°]
± 90
Maximum FOV [cm] @ SID = 100cm 50 x 50
Minimum FOV [cm] @ SID = 180cm 4.5 x 4.5
Power supply: DC input voltage [V]
24 ± 10%
Max. DC input current [A] 2
AC input voltage [V]
37 ± 10%
Max. AC input current [A]
Lamp type
7
Philips 12999: 12v, 50W
Temperature: Operation [°C]
5 ≤ T ≤ 40
Transport and storage [°C]
-40 ≤ T ≤ 70
Humidity: Operation [%]
10 ≤ T ≤ 90, non-condensing
Storage [%]
5 ≤ T ≤ 95, non-condensing
Pressure: Operation [hPa]
650≤ T ≤ 1013
Storage [hPa]
525 ≤ T ≤ 1013
Inherent filtration 1,0 mm Al at 70 kV
Leakage radiation < 0,5 mGy/ h
Rectangular blade positioning accuracy ±2mm@SID=1m
Rectangular blade positioning repeatability ±1mm@SID=1m
