5-3-4 Console Indicator
1. System error Led If there is any system error, this Led will
be on.
2. Thermal error Led If tube temperature is over limitation, this
Led will be on.
3. Error message When any error occur, console will
display some error message and error
code: technique error, parameter error,
AEC error, rotor thermal error, inverter
thermal error, tank thermal error, Door
Open in exposure.
4. PREP Led Press and hold PREP button, the PREP
lamp will be on.
5. Exposure Led During X-ray emission, this lamp will be
on.
6. Buzzer During X-ray emission, it will be on.
7. Turn auto/manual switch Manual lamp on or off
8. Table in PBL: when table in
center, SID in detent, Cassette
in place (if have tray selected)
Exposure ready is on, or exposure holder
is on
9. WALL in PBL: when wall SID
in detent, Cassette in place
Exposure ready is on, or exposure holder
is on
10. TOMO in PBL: when table in
center, SID in detent Cassette
in place (if have tray selected)
Exposure ready is on, or exposure holder
is on
11. IN manual Exposure ready is on, exposure holder is
off
FOR TRAINING PURPOSES ONLY!
