GE Proteus XR/a - Multileaf Collimator Rear View

PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
7-11
7-6-4 Rear View of Multileaf Collimator
(1) Locking lever for ± 90° rotation of collimator around vertical axis
ILLUSTRATION 7-11
AUTOMATIC COLLIMATOR REAR VIEW
Identification
labels
1
Locking lever for
± 45° rotation of
collimator around
vertical axis
Lamp housing
of light localizer
