GE Proteus XR/a

PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
8-2
1 Vertical Column
2 AEC Detector Areas
3 Bucky Film Cabinet
4 Vertical Lock Release
5 Cassette Tray
6 Vertical Motion
*7 LAT Grab Bar
*8 PA Grab Bar
*9 Knee Spacer
Note: The content with a star is only for the wall stand with a knee spacer.
1
3
8
4
7
5
9
ILLUSTRATION 8-2
*WALL STAND
FOR TRAINING PURPOSES ONLY!
