ELECTROMAGNETIC COMPATIBILITY (EMC) (CONT.)
Guidance and manufacturer’s declaration - Electromagnetic Immunity (1)
The Proteus XR/a system is suitable for use in the specified electromagnetic environment. The
purchaser or user of the Proteus XR/a system should assure that it is used in an electromagnetic
environment as described below:
Immunity Test IEC 60601-1-2
Test Level
Compliance
Level
Electromagnetic Environment
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors are wood, concrete, or ceramic
tile, or floors are covered with synthetic
material and the relative humidity is at
least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for
input/output
lines
±2 kV for
power supply
lines
±1 kV for
input/output
lines
Mains power quality is that of a typical
commercial and/or hospital environment
Surge
IEC 61000-4-5
±1 kV differential
mode
±2 kV common
mode
±1 kV
differential
mode
±2 kV common
mode
Mains power quality is that of a typical
commercial and/or hospital environment.
Voltage dips,
short
interruptions
and voltage
variations on
power supply
input lines
IEC 61000-4-11
< 5 % U
T
(> 95 % dip in UT)
for 0.5 cycle
40 % U
T
(60 % dip in UT)
for 5 cycles
70 % U
T
(30 % dip in UT)
< 5 % U
T
(> 95 % dip in UT)
for 5 s
0 % U
T
for 5
sec
Mains power quality is that of a typical
commercial and/or hospital environment.
If the user of the Proteus XR/a system
requires continued operation during
power mains interruptions, it is
recommended that the Proteus XR/a
system be powered from an
uninterruptible power supply or a battery.
Power
frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m
Power frequency magnetic fields are at
levels characteristic of a typical location
in a typical commercial and/or hospital
environment.
Note: These are guidelines. Actual conditions may vary.
